Southbend 4484DC-3GL-LP 48" Liquid Propane Ultimate Restaurant Range - 175,000 BTU
Shop all Southbend Commercial Gas Range
- SKU:
- 4484DC-3GL-LP
- MPN:
- 4484DC-3GL
This product comes with warranty coverage. Warranty terms vary by product and part type. See full warranty details.
Commercial design services
Discover a whole new degree of kitchen customization with our proven idea-through-installation model. Learn more
Southbend 4484DC-3GL-LP features a 48" stainless steel worktop, two burners, a 36" griddle, 175,000 BTU, a standard oven, cabinet base, 22.5" flue riser, and adjustable legs.
- 22.5" flue riser, hi-shelf, 1 rack
- Standard oven 70.9 Cu.Ft volume
- Manual controls, standing pilot, spark ignition
- 48" liquid propane range, 175,000 BTU
- Stainless steel front, sides, shelf, 6" legs
- 36" griddle, .500" plate thickness
Weight735 LBS
Height59.5 (H)
Width48.63 (W)
Depth34 (D)
Base(1) Standard Oven, (1) Cabinet
Cook Top37.00
Cubic Volume70.9 Cu.Ft
Door Opening15.50"
Exterior FinishStainless steel
Flue Riser22.5 Flue Riser Standard
Legs6" Adjustable Legs
No of Burners2
Number of Racks1
Oven Bottom13.00"
Oven DoorSpring assisted, counterweight door
Oven Interior (WidthxDepthxHeight)26.00"Wx26.50"Dx14.00"H
Plate Thickness.500" = 1/2"
TopBurners with Left Griddle
Total BTU175,000 BTU
VentBackriser with hi-shelf
Voltage120
ManufacturerSouthbend
Amps5.9
Phase1
Hertz60
Control TypeManual
Power TypeLiquid Propane
| Weight | 735 LBS |
|---|---|
| Height | 59.5 (H) |
| Width | 48.63 (W) |
| Depth | 34 (D) |
| Base | (1) Standard Oven, (1) Cabinet |
| Cook Top | 37.00 |
| Cubic Volume | 70.9 Cu.Ft |
| Door Opening | 15.50" |
| Exterior Finish | Stainless steel |
| Flue Riser | 22.5 Flue Riser Standard |
| Legs | 6" Adjustable Legs |
| No of Burners | 2 |
| Number of Racks | 1 |
| Oven Bottom | 13.00" |
| Oven Door | Spring assisted, counterweight door |
| Oven Interior (WidthxDepthxHeight) | 26.00"Wx26.50"Dx14.00"H |
| Plate Thickness | .500" = 1/2" |
| Top | Burners with Left Griddle |
| Total BTU | 175,000 BTU |
| Vent | Backriser with hi-shelf |
| Voltage | 120 |
| Manufacturer | Southbend |
| Amps | 5.9 |
| Phase | 1 |
| Hertz | 60 |
| Control Type | Manual |
| Power Type | Liquid Propane |
